Anticorrosive Solenoid Valve 220VAC from China manufacturer

Payment Terms:	T/T,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: ZCF

Production Capacity: 1000000/week

Delivery Date: 7days after receive the pay...

Standard or Nonstandard: Standard

Structure: Safety

Temperature of Media: Medium Temperature

Brand Name: ROUND STAR

Function: an electromechanical valve ...

Company spirit: o challenge our future and ...

Company style: o be faithful,practical, co...

Means of Transport: Ocean,Land,Air

Packing: carton

Power: Solenoid

Pressure: Low Pressure

Material: Alloy

Media: Others

why us ?: more than 40 years since 19...

Export Area:: ALL OVER THE WORLD

Company value: to make wealth for society ...

Market conception:: what we do will be based on...

Corrosion solenoid valve
the material is upvc or cpvc
pilot operated
the seal material is EPDM or FKM
suit for strong acid or alkali liquid/ga

ZCF-25P Anticorrosive Solenoid Valve

:[Technical Specifications ]
-- Media: Corrosive Fluid
--Function type: Normally Closed (N/C)
--Temperature: 0 ÷ 80℃
--Mode of action: Direct acting type
--Body material: upvc
-- Sealing material: fkm or epdm
--Protection class: IP54

model	orifice	connection size	(MPa)pressure	max (MPa)	Cv
ZCF-15P	15	G1/2	0.01~0.6MPa	1.5MPa	4	±10%	AC220V,DC24V,	EPDM\FKM
ZCF-20P	20	G3/4			5.5
ZCF-25P	25	G1			13
ZCF-32P	32	G1¼			17
ZCF-40P	40	G1½			25
ZCF-50P	50	G2			40

model	ZCF-15P	ZCF-20P	ZCF-25P	ZCF-32P	ZCF-40P	ZCF-50P
	G1/2	G3/4	G1	G 1 ¼	G 1½	G 2
L	74	80	100	120	130	172
H	132	137	147	171	180	225
W	63.5	63.5	74	94	94	155
C	63.5	63.5	74	94	94	155
A	16	19	26	30	32.5	42
K	92	92	92	94	94	94
